CF Tuff-Cast™

Metl-Span’s CF Tuff-Cast™ profile is an appealing-insulated metal panel given its appearance of finished precast concrete. The exterior surface of the concrete look exterior panel is a hard aggregated fiber reinforced polymer coating and is created with the factory-applied Tuff Cote® finish system, which offers an extremely durable, impact and abrasion-resistant coating that can withstand severe weather conditions.

The wall panel’s exterior provides your building with an attractive precast concrete building alternative while maintaining energy efficiency. Since the panels have a double tongue-and-groove joint system, the cost of labor is reduced significantly when a building is constructed. This joint system also creates a barrier that is air, vapor, and water-resistant.

The CF Tuff-Cast profile is available in a variety of color options, along with either vertical or horizontal textures.

Coverage Width	36″, 42″
Thermal Values – R-Value & U-Factor	*U-Factor (BTU/h-ft2Fahrenheit) Panel Width: 42″ 2″ = 0.058 2.5″ = 0.045 3″ = 0.038 4″ = 0.028 5″ = 0.022 6″ = 0.019 R-Value (hft2F/BTU)** Panel Width: 42″ 2″ = 17.9 2.5″ = 22.4 3″ = 26.9 4″ = 35.9 5″ = 44.8 6″ = 53.8
Exterior Face	G-90 galvanized or AZ-50 aluminum-zinc coated steel in 24 and 22 Ga.
Interior Face	G-90 galvanized or AZ-50 aluminum-zinc coated steel in 26, 24 and 22 Ga.
Exterior Texture	Tuff Cote® finish system—a hard aggregated fiber-reinforced polymer coating.
Finishes	Applied Finishes, Igloo White
Joint	Offset double tongue-and-groove with extended metal shelf for positive face fastening.
Length	8′-0″ to 32′-0″ for Horizontal 8′-0″ to 40′-0″ for Vertical

*K-Factor calculations: BTU in/ft²hr. °F

**Based on ASTM C518, ASTM C1363 and thermal modeling

+5″ and 6″ CF Tuff-Cast and Tuff Wall available with Mesa, nominal 1/8″ deep profile only
